WADS – 201 / 202 / 203 / 204

DEW POINT SENSOR

The Wiseair Dew Point Sensor provides reliable and long-term stable dew point monitoring in industrial applications, with a range of -110 … +60 °C Td. It makes it an ideal choice for dew point measurements in high tech requirements and conditions.

The new generation of the dew point sensors offering compressed air users a plug & play solution to monitor their compressed air quality. All transmitter models are available with Analog 4… 20 mA output signals, in addition to that the models are available with a Modbus/RTU digital interface. By offering different output signals users can profit from great flexibility and seamless integration into their process.

Additionally, the dew point sensors are offered with an integrated pressure sensor, combining a pressure and dew point sensor into a single instrument. The main body is made from high class aluminium alloy with a soft finish. Top cover made from aluminium at the same quality as the main body.

Features :

• For high tech applications with a measurement range of -60°Ctd to +60°Ctd & -80°Ctd to +20°Ctd
• Quick Response Time
• Dual Sensor System for high precision over the whole range.
• Compact size makes them ideal for dryer installations.
• Accuracy ± 2°C IP65 rated
• Strong contamination resistance
• Signal Output: Modbus RTU interface and 4-20mA current / pulse output.
• Modbus output signal are Pressure Dew Point (PDP), Relative Humidity, Temperature and Optional Integrated pressure transducer
• 4-20mA output signal are Pressure Dew Point (PDP)
• CE marked in accordance with applicable EU Directives.
  Declaration of Conformity available upon request.
